1/6 And 1/6 Gauge Pattern Loop Machine

Introduction

Destined for contract and commercial market, this machine allows you to make large free flowing patterns with timeless designs.

Yes! These timeless patterns come off one of our multi loop tufting machines with 1/6 and 1/6 gauge.

Parameters

• Machine size:

  2m L*W*H6.6*2.2m*3m

  4m L*W*H8.6*2.2m*3m

• Working width: 2m or 4m

• M/C Gauge: 1/12'', 1/6" +1/6'' front and rear two needle bars

• Pile height: 2.5-9mm

• Mechanical speed: 1000RPM

• Stitch rate: 25-60 stitches/10cm

• Total power ref.: 2m 40kw

                       4m 55kw

• Double sliding needle bar with cam

• Customized yarn feeding servo motor

• Independent control yarn feeding

• Servo motor + planetary reducer feeding of primary back

• Puller roller control led by servo motor

• Pattern control software

• Operation setting on touch screen.




Packaging and Delivery

Packing details

• Wrapping film with steel wire fixed for main machine or steel frame for the main machine

• Wooden case or carton for small parts packing.

Shipping details

• Always test running before each shipping

• Strictly inner inspection before each loading

• Loading photos or videos available once loaded
